Media Alert

15 May 2009

Cortex-Mx Microcontroller Prototyping System

Plano, TX: Keil announce the Microcontroller Prototyping System (MPS), enabling evaluation and prototyping of ARM® Cortex™-Mx processors and user defined peripherals in a single product. The Keil MPS is the first prototyping system incorporating a full-speed Cortex-M0 or Cortex-M3 processor implemented in FPGA which can be integrated with third-party peripheral IP to deliver a prototyping system for hardware and software application development.

The MPS enables ARM Partners to implement a Cortex-M class system without having access to the processor RTL, meaning different processors can be benchmarked in order to choose the most suitable for the intended devices price/performance. Additionally, the MPS is delivered fully configured with the Cortex-M processor and is fully tested so that the user does not have to test the processor implementation and can immediately begin adding third-party IP or writing software.

Features

• Cortex-M™ class processor running at up to 50MHz
• On-system memory: 64MB NOR Flash, 8MB SRAM
• 10/100 Ethernet Phy to DUT FPGA
• USB 2.0 Full Speed - USB-OTG, USB Host
• 4 UARTS: 2 fixed and 2 configurable as either UART or FlexRay/CAN
• DVI-A video DAC support for 1280x1024 resolution
• SD/MMC Card Interface
• AC97 Audio codec supporting Line-in, Line-out and internal speaker
• 2x20 Character LCD display plus user buttons and LEDs
• Large FPGA prototyping system based on an Altera Stratix III enables users to incorporate third-party peripherals and IP
• JTAG interface and ETM Trace port (Mictor-38 connector)
• Altera Quartus II Webpack to build and download the MCU or SoC hardware design to the FPGA via USB
• Keil ULINK2 and MDK-ARM (evaluation version) to develop application software
• Full information is available at www.keil.com/mps
