Block Diagram Schematics Technical Data Prototyping Area Microcontroller Power Supply Configuration JTAG Interface ETM Interface LEDs Serial Ports CAN Interface Ethernet Interface SD/MMC Connector USB Interface Push Buttons Potentiometers Speaker QVGA Module Accelerometer IrDA Writing Programs Example ProgramsSD/MMC Connector
The MCB2470 board supports one SD/MMC memory card connector that allows you to connect a wide range of SD/MMC memory cards.
The MCB2470 board provides 2 LEDs that indicate the status of the SD/MMC card:
- The /WP LED indicates WRITE-PROTECT signal is active(low).
- The CD LED indicates that CARD-DETECT signal is active(low) and that an SD/MMC card is detected.
