Introduction

The ARM7TDMI based MCB2470 Evaluation Board allows you to generate and test application programs for the NXP (formerly Philips) LPC24xx microcontroller family. With this hands-on process, you can determine the hardware and software requirements for current and future product development.

The MCB2470 Evaluation Board ships with the LPC2478 device that is a superset of several other device variants of the LPC24xx microcontroller series. The MCB2470 Board contains all the hardware components required in a single-chip LPC24xx system.

The MCB2470 Evaluation Board also includes a 320x240 TFT LCD QVGA color display module with a built-in touchscreen.

MCB2470 Board

MCB2470 Board
