Block Diagram Schematics Technical Data Prototyping Area Microcontroller Power Supply Configuration JTAG Interface LEDs Serial Ports CAN Interface Ethernet Interface SD/MMC Connector USB Interface Push Buttons Potentiometers Speaker QVGA Module Writing Programs Example ProgramsSD/MMC Connector
The MCB2400 board supports one SD/MMC memory card connector that allows you to connect a wide range of SD/MMC memory cards.
The MCB2400 board provides 3 LEDs that indicate the status of the SD/MMC card:
- The /WP LED indicates WRITE-PROTECT signal is active(low).
- The CD LED indicates that CARD-DETECT signal is active(low) and that an SD/MMC card is detected.
- The PWR LED indicates that 3.3 VDC power is present to the SD/MMC card connector.
